SEKURER CCTV IP Camera Tester Monitor, 8MP AHD CVI TVI CVBS IP Camera Test 4K HD Display Video Monitor 5inch IPS Touch Screen IPC Tester Support POE PTZ WiFi RS485 HDMI & VGA Input DC12V Output : Electronics
Original price was: $295.00.$175.00Current price is: $175.00.
【IP Camera Tester】Network camera tester support max 12MP 4K H.265/H.264 IP PoE Camera test. Powerful network tools to help you detect and set various network parameters. Support PoE IEEE802.3af/at 48V, maximum power 25.5W, UTP cable test, POE test RJ45 TDR cable test. 【4-in-1 Coaxial CCTV camera test】Support max 8MP(3840x2160P) TVI / AHD / CVI camera test, support UTC PTZ control and call OSD menu. Built-in “Auto HD” APP can automatically recognize the camera type when viewing HD AHD / TVI / CVI cameras. And CCTV tester also support CVBS analog camera test. [Professional testing tools] Built-in special tools for Hik and DH, support batches of fast setting of Hik and DHcameras. At the same time, it has built-in dedicated testing tools for other brands of cameras, which can be compatible with most existing cameras. Use it to make your installation simple and efficient. 【Multi-function tester】: CCTV tester has a 5 inch 1920x1080P touch screen that can display its genuine resolution of the IP camera images. Built-in media player. Built in WiFi, create WIFI hotspot. VGA & HDMI Input, LED lamp, calculators, support snapshot, video record & playback; The camera tester uses Android system, so you can also install the APP you need. 【100% Satisfaction Guarantee】：We tested every cctv camera tester before we sent it to the Amazon warehouse, to ensure that you will not receive defective products. We offer 24h technical support and 1 year warranty. The security camera tester is powered by a 7.4V/3350mAh lithium-ion battery and can operate for up to 6 hours after 3-4 hours of charging.
Product Description
● 5 inch IPS touch screen, 1920*1080 resolution
● H.265 & H .264 IP, 4K video display via mainstream
● Analog camera test, PTZ controller
● 8MP TVI test, 3840 x 2160P 12.5/15 FPS, 4xzoom, video record & playback, coaxial PTZ control & call OSD menu
● 8MP AHD test, 3840 x 2160P 15 FPS, 4xzoom, video record & playback, coaxial PTZ & call OSD menu
● 8MP CVI test, 3840 x 2160P 12.5/15FPS, 4xzoom, video record & playback, coaxial PTZ & call OSD menu
● Auto HD app, auto recognize HD coax camera type and resolution, support snapshot, video record & playback, coaxial PTZ & call OSD menu
● IP and analog display image at the same time
● IPC TEST, HIK camera test tool, DH camera test tool
● DC12V/3A power output, the camera can be powered from DC 12 Voltage
● Rapid video, just by one key to detect all network cameras and auto display
● Built-in Wi-Fi, display image from the wireless camera, create WIFI hotspot
● VGA input, up to 2048 x 1152 60FPS, support snapshot, video record & playback*
● HDMI Input, up to 4K 30FPS, support snapshot, video record & playback*
● Rapid Network Camera Test, Auto log in and display image, create testing report
● IPC test pro, auto-scan all network segments IP, auto open PoE power and display the power. Input username and password, can scan camera image, can batch activate IP camera. Jump to the app interface and test tools.
● Support multiple big brands cameras tests, enter the app, input username and password to test
● HIK camera test tool, support batch activate HIK cameras and modify IP address, modify password etc. Self-defined modify channel name, can quickly change H.264 and H.265 video, open wide dynamic mode. Factory restore, etc.
● DH camera test tool, support batch activate DAHUA cameras and modify IP address, user name and password. Self-defined modify channel name
Other Functions:
● Network tool: Ping, IP scan, Port Flash, DHCP server, Trace Route
● Tester Play: Tester, android version mobile phone and PC display at the same time
● Traffic monitoring, display network port or WIFI connection real-time upload and download speeds and other network parameters
● Customers self-update software, you can install apps with android version
● Media player, 4K video files and MKV/MP4 media files play
● Display its genuine resolution of the IP camera images
● Audio in, support record and save the audio/LED lamp, calculators, music players and other application tools
● 7.4 V /3350mAh Lithium Ion Battery, after 3-4 hours charging, working time lasts 6 hours (For IPC-5100 Plus and IPC-5200 Plus)
● 7.4 V /2600mAh Lithium Ion Battery, after 3-4 hours charging, working time lasts 5 hours (For IPC-5000 Plus)
Cable test:
● Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, can save testing report, if special number, need customized. Can detect the near-end, mid-end and far-end fault point of the RJ45 cable plug
● RJ45 TDR cable test, test cable pair status, length, attenuation, reflectivity, impedance, skew etc, can create test report
● Digital Cable tracer, search BNC cable, network cable and telephone cable from the mess cables. Cable search and UTP cable can test at the same time
| Package Dimensions | 10.3 x 5.8 x 4.1 inches |
|---|---|
| Item Weight | 2.44 pounds |
| ASIN | B07T5JVJ2C |
| Batteries | 2 Lithium Ion batteries required. (included) |
| Customer Reviews | /* .cm-cr-review-stars-spacing-big { 4.2 4.2 out of 5 stars P.when('A', 'cf').execute(function(A) { 4.2 out of 5 stars |
| Best Sellers Rank | #64 in Security Monitors & Displays |
| Date First Available | June 12, 2019 |
| Manufacturer | EVERSECU |
7 reviews for SEKURER CCTV IP Camera Tester Monitor, 8MP AHD CVI TVI CVBS IP Camera Test 4K HD Display Video Monitor 5inch IPS Touch Screen IPC Tester Support POE PTZ WiFi RS485 HDMI & VGA Input DC12V Output : Electronics
Only logged in customers who have purchased this product may leave a review.
Jared willet
Best cctv monitor I’ve used so far!
Samuel R. Gelner
Had to pick up one of these for an install job I had. 127 cameras at a big site. I’ve tried a couple other monitors, and they worked, but on some, you had to spend time trying to get through their convoluted setup configurations, or the display resolution wasn’t high enough, so you’d lose part of the image and have to guess if you were on point or not. this monitor worked out of the box, has most of the addons you need (though admittedly, most cameras come with needed accessories anyway). Some sort of screen protector would be nice too, though I haven’t found one that fits yet.
Lisa Matson
We bought this device for use at our church. It has helped me diagnose and see the video coming from the cameras both locally and at our media center. This device enabled me to troubleshoot issues that I was having with HDMI and SDI signals going into our video switch and we now have all working! Great simple to use device for our needs. Thank you!
Terol Solomon
Awesome device, where has this been all my years of installing cameras? Having this device made troubleshooting, positioning, and aiming so much easier. No more up-and-down ladders this eliminated all of that. This device is having a second guy onsite with you that you don’t have to pay it’s paying you!!!.
Carlos Cortes ChavesCarlos Cortes Chaves
El tester está muy bien y cumple con lo que dice la descripción para lo que es para la cámaras pero el Traker o tester de red no llego el que sale en el video solo llego uno pequeño y esperaba que llegara el grande que sale en la publicación me siento decepcionado que pasará esto.
Joseph Pappalardo
I really like this tester. I’ve used this thing practically everyday and performs as needed. The cost of this device compared to other spot monitors was a huge selling point for me and it’s worked out in my favor.
slt
I’m an independent IT source who only rarely does anything with CCTV but still needs to support his clients. This fit the bill for basic features and performance at a very budget price. I’m very happy. I think the best recommendation I would make for the manufacturer would be a small, basic shell case to hold the unit and it’s accessories securely while preventing damage in a tool bag or box but that’s about it. The rest was good. Documentation was typical but as this was a “professionally targeted” product, I don’t think most buyers will need much. All in all, a win at the price point.
